SYNCO Mic-M1S

Small Camera Microphone for Smartphone SYNCO M1S

SYNCO Mic-M1S, a small camera microphone, provides mobile vloggers, video creators, and journalists with easy use experience and excellent sound performance. Of this, the upgraded shock absorption design tries to decentralize the vibrations and minimize the resulting noises, the ultra-compact size allows the microphone to sit comfortably on the recording devices without any setback for each operating, and the cardioid condenser guarantees excellent sound results.

Free Action, Smooth Recording

The upgraded shock absorption design that tries to share the vibrations with 4 rubber rings enables the camera microphone to minimize the resulting noises.
The ultra-compact size, 72mm long and 35g light, allows it to sit comfortably on the camera and even smaller mobile devices,
having no impact on any of your operating. Both are intended to relieve the stress on your shooting.

SYNCO Mic-M1S Free Action, Smooth Recording
SYNCO Mic-M1S Enhanced Input, Improved Output

Enhanced Input, Improved Output

The inbuilt Φ14 microphone condenser processes audio signals finely with low self-noise, and the cardioid pickup highlights the target sound and meanwhile, attenuates the unwanted background noises, thus offering excellent sound effect.

Out-of-the-box Functionality

The small microphone SYNCO M1S needs no battery and has no buttons on the microphone. Just plug it in your device and start your run-and-gun production.

SYNCO Mic-M1S Out-of-the-box Functionality

All-device Compatibility

The included 3.5mm TRS/TRRS cables guarantee easy connections between the directional microphone and cameras, smartphones, tablets, and Mac.
The 1/4" thread at the bottom of the silicone shock mount is open to cameras, gimbals, tripods, boompoles, and stands.
In particular, it is a perfect companion for SYNCO Vlogger Kit 1 and SYNCO Vlogger Kit 2

SYNCO Mic-M1S All-device Compatibility
SYNCO Mic-M1S

SYNCO Mic-M1S is the small camera microphone providing mobile vloggers, video creators, and journalists with easy use experience and excellent sound performance.

Free Action, Smooth Recording

The upgraded shock absorption design and the ultra-compact size are combined to allow free moving and unimpeded recording.

SYNCO Mic-M1S Free Action, Smooth Recording

Ultra-flat Frequency Response

The frequency response range is 20Hz—20KHz. With ultra-flat frequency response, Mic-D2 outputs all the frequencies that we can hear at once and produces accurate natural sound from the source.

Enhanced Input, Improved Output

The Φ14 condenser for fine processing of signals and the cardioid pickup for precise capture work together for excellent sound output.

SYNCO Mic-M1S Enhanced Input, Improved Output

Out-of-the-box Functionality

SYNCO M1S needs no battery and has no buttons - it runs once plugged in your device.

SYNCO Mic-M1S Out-of-the-box Functionality

All-device Compatibility

The included accessories guarantee its connections with varied devices such as cameras, phones, gimbals, and stands.

SYNCO Mic-M1S All-device Compatibility

Specifications

TransducerCondenser
Polar Pattern
Cardioid
Frequency Response
100Hz-20KHz/ ±3dB
Signal/Noise>60dB
Max. SPL
130dB@1KHz, 1%THD
Sensitivity-35dB re 1 Volt/pasal (18.00mV@94dB SPL)
+1/-2dB@1KHz

Power Requirement
Plug-in Power
Connector3.5mm TRS/3.5mm TRRS
Dimensions
Φ21.5x 72mm
Net Weight
35g

Specifications

TransducerCondenser
Polar Pattern
Cardioid
Frequency Response
100Hz-20KHz/ ±3dB
Signal/Noise>60dB
Max. SPL
130dB@1KHz, 1%THD
Sensitivity-35dB re 1 Volt/pasal (18.00mV@94dB SPL)
+1/-2dB@1KHz

Power Requirement
Plug-in Power
3.5mm TRS/3.5
Connector
3.5mm TRS/3.5mm TRRS
Dimensions
Φ21.5x 72mm
Net Weight
35g

Showcase

Showcase

SYNCO Vlogger Kit 1
SYNCO Vlogger Kit 1
SYNCO Vlogger Kit 1 Application
SYNCO Vlogger Kit 2
SYNCO Vlogger Kit 2
SYNCO Vlogger Kit 2 Application
SYNCO MMic-U1
SYNCO MMic-U1
SYNCO MMic-U1
SYNCO Mic-M2S
SYNCO Mic-M2S
SYNCO Mic-M2S
SYNCO Vlogger Kit 1
SYNCO Vlogger Kit 1
SYNCO Vlogger Kit 1 Application
SYNCO Vlogger Kit 2
SYNCO Vlogger Kit 2
SYNCO Vlogger Kit 2 Application

Quickstart Guide

  • Place the small shotgun microphone into the shock mount. Make sure the mic is well balanced and securely sit.
  • Cover the front of the microphone with the windshield.
  • Connect the microphone to the device using the included microphone cable:
  • For CAMERA series such as camera, camcorder, audio recorder, and other audio video recording devices, use the cold shoe to attach the shock mount to the camera and then connect the camera microphone to the device with the 3.5mm TRS camera cable.
  • For PHONE series such as smartphone, tablet, and Mac, use the cold shoe or the thread to get the shock mount attached to the smartphone holder (not included) and then connect the external microphone to the device with the 3.5mm TRRS phone cable.
  • Open the audio/ video recording App on your device and start your recording.

Quickstart Guide

  • Place the small shotgun microphone into the shock mount.
  • Cover the front of the microphone with the windshield.
  • Connect the microphone to the device using the included microphone cable:
  • CAMERA series: use the cold shoe to attach the shock mount to the camera and then connect the camera microphone to the device with the 3.5mm TRS camera cable.
  • PHONE series: use the cold shoe or the thread to get the shock mount attached to the smartphone holder (not included) and then connect the external microphone to the device with the 3.5mm TRRS phone cable.
  • Open the audio/ video recording App on your device and start your recording.
